Firma 1900Kv Brushless Motor

Firma 1900Kv Brushless Motor

Spektrum - Item No. SPMXSM1600
3.8 out of 5 Customer Rating
$104.99
RC Club points earned on this item shown at checkout.
Complete Your Product

Firma 1900Kv Brushless Motor

Safe-D Shaft with C-Clip Locking Point to Prevent Pinion Gear Slip

5mm Diameter Steel Output Shaft

4mm Gold Plated Bullet Connectors

130A ESC

Quick Links

icon-pdf-download Manuals & Support

Overview

The Firma 1900Kv brushless motor is a perfect option for 1/8 scale buggy, truggy or monster trucks with a 3S-6S LiPo powered setup. Featuring a low cog 4-pole 8-magnet rotor design, CNC machined aluminum housing, insulated high purity copper windings, high-quality alloy steel 4mm output shaft, and precision bearings for high durability and smooth rotation. Preinstalled with 4mm gold plated bullet connectors for easy installation, and perfectly matched for the Firma 130 Smart ESC.

Features

  • Perfect upgrade for 1/8 scale racers and bashers
  • Safe-D Shaft provides a C-clip locking point to prevent pinion gear slip
  • High efficiency design
  • 6S LiPo power capable
  • High-quality 4-pole sintered rotor
  • 4mm gold plated bullet connectors
  • High-quality construction with precision ball bearings and hardened steel 5mm shaft

PRODUCT SPECS

Application
Upgrade for 1/8 scale racers and bashers with 3-6S Lipo powered setup
Bushing Or Bearing
Bearing
Connector Type
4mm Bullet
Efficiency
86%
Input Voltage
11.1 - 22.2V
Maximum Continuous Current
60A
Motor Class
1/8 Scale
Motor Design
Inrunner
Motor Size
4274
Motor Type
Brushless
Number of Poles
4
Outer Diameter
1.6 in (42 mm)
Output
4940W
Part Type
Electronics
Product Length
2.9" (74 mm)
Product Weight
14.67 oz (416 g)
RPM/Volt (Kv)
1900Kv
Sensored
No
Shaft Diameter
0.19" (5 mm)
Shaft Length
0.73 in (18.5 mm)
